7 VIDEO (N (AV2)
Connects a video cable from a movie camera or another
unit.
8 AUDIO IN (AV2)
Connects an audio cable from a movie camera or
another unit.
9 Infra-red Remote Control Receiver Window
10 CVC (Crystal View Control) Indicator
This indicator is lit when the VCR is on.
11 Dispiay
12
Selects the required programme position (TV station) of
the VCR.
For tracking adjustment and vertical locking adjustment.
•For manual tracking adjustment
The V and ^ buttons are used to adjust the tracking
when, for example, noise bars on the picture during
normal playback are better removed manually than by
automatic digital tracking control. To return to automatic
digital tracking control, press both buttons together.
• For slow tracking adjustment
When noise bars appear during still or slow playback,
switch over to slow playback and adjust with the s/ or
button to reduce the noise bars.
• For vertical locking adjustment
Use the v and / n buttons to minimize any vertical
jitter during still picture playback.
Set VCR/TV switch to VCR for using the V and
buttons of remote controller.
0)
REAR g)
vP
17 VIDEO IN (AVI)
^
Connects a video cable from a movie camera or another qq
unit.
18 VIDEO OUT
Connects a video cable to a TV or another unit.
19 RFIN
Connects the external aerial.
20 AC IN-
Connects the main power supply.
21 AUDIO IN (AVI)
Connects an audio cable from a movie camera or
another unit.
22 AUDIO OUT
Connects an audio cable to a TV or another unit.
23 RF OUT
Connects the aerial terminal on a TV.
13 • REC/OTR
Starts recording.
For One-Touch Recording (OTR).
14 TIMER REC El
Turns the timer recording function on and off.
El is lit or not lit.
Once you operate the timer recording function, normal
VCR operation is not possible unless you press this
button again and release the VCR from the timer
recording standby mode.
15 STOP ■ (0)
Stops playback or recording.
Ejects the video cassette.
16 PLAY/OFF El ►
Starts playback. “O" is tit.
For the Play-Off Timer function.
