■Specifications
NV-HD630A/EA
Vìdeo Recording System:
Video Heads:
Audio Heads:
Tape Speed:
Tape Format:
Record/Playback Time:
FF/REWTime:
VIDEO
Television System:
Modulation System;
Input Level;
Output Level:
AUDIO
Input Level:
Output Level:
Audio Track:
Video Horizontal Resolution;
Signal-to-Nolse Ratio;
Dynamic Range
Audio Frequency Response:
Wow and Flutter:
Operating Temperature:
Operating Humidity:
Weight:
Dimensions;
Standard Accessories:
4 rotary heads, helical scanning system
4 heads
2 heads
PALSP:
NTSC SP:
VHS tape
PALSP:
PAL LP;
23.39 mm/s
33.3 mm/s LP:
EP:
117 mm/s
11.1 mm/s
240 min with NV-E240
480 min with NV-E240
Approx. 60 s with NV-E180
CCIR; 625 lines, 50 fields, PAL colour signal
EIA; 525 lines, 60 fields, NTSC colour signal
Luminance; FM azimuth recording
Colour signal; converted subcarrier phase shift recording
VIDEO IN (PHONO): 1.0 Vp-p,
VIDEO OUT (PHONO): 1.0 Vp-p.
RF modulated;
UHF channel AU28-69 (NV-HD630A),
NZ21-69 (NV-HD630EA),
75 ohm, terminated
75 ohm, terminated
75 ohm
75 ohm
AUDIO IN (PHONO): -6 dBV, more than 47 kohm
AUDIO OUT (PHONO); -6 dBV, less than 1 kohm
1 track (normal-mono only), 2 channels (Hi-R sound-stereo)
Colour; more than 240 tines (SP)
Video; more than 43 dB (SP)
Audio; more than 90 dB (Hi-Fi audio track)
20 Hz-20 kHz/Hi-Fi
0.005% Wrms/Hi-R
5“C-40“C
35%-80%
3.9 kg
430 (W)x87 (H)x300 (D) mm
1 pc. RF coaxial cable 1 pc. remote controller
2 pcs. "RS” size batteries 1 pc. AC mains lead
1 pc. audio video cable
Weight and dimensions shown are approximate.
Specifications are subject to change without notice.
