7.1ch Audio Reformatting
Surround sound with 6.1ch or less is automatically expanded
and played back at 7.1ch.
• If "Off" is selected, sound is played over the original number
of channels (Note that in the case of 6.1ch audio, playback
will be at 5.1ch.)
Audio reformatting is enabled in the following cases:
• When you have selected “PCM" in “Digital Audio Output".
• When the audio is Dolby Digital, Dolby Digital Plus, Dolby
TrueHD or LPCM.
High Ciarity Sound
When connected to TV via HDMI AV OUT terminal for
outputting image, it produces clearer sound because the
analog video circuit (via VIDEO OUT terminal) can be stopped.
• Set to “Enable" and then set “High Clarity Sound" on the
playback menu to “On", (o 35)
Audio Deiay
Mis-sync between the video and audio is corrected by delaying
the audio output.
Speaker
Refer to page 39
HDMi Connection
Press [OK] to show the following settings.
Display
Status Messages
Choose whether to show status messages automatically.
On-screen Language
Choose the language for these menus and on-screen
messages.
Screen Saver Function
This is to prevent burn-in on the screen.
• When this is set to “On":
If there is no operation for 5 minutes or more, the displayed
screen switches to the other states automatically.
FL Dispiay
Changes the brightness of the unit’s display.
• If “Auto" is selected, the display is dimmed but brightens
when you perform some operations.
FL Controi (Voi 0)
• If “On" is selected, the unit’s display will turn off when the
volume is adjusted to “ 0 ".
License
Information about the software used by this unit is displayed.
I TV / Device Connection
TV Aspect
Set to match the type of television connected.
When connected to a 4:3 aspect television and playing 16:9
ratio image:
The sides are cut off so the
picture fills the screen. i
When playing BD-Video, i
video is output as “4:3 i
_e;;erbox".
i
4:3 Letterbox 3 bands appear at the
top and bottom of the
picture.
When connected to a 16:9 widescreen television and playing
4:3 ratio image:
16)9--------
HDMI Resolution
The items supported by the connected devices are
indicated on the screen as When any item without
is selected, the images may be distorted.
• If “Auto" is selected, automatically selects the output
resolution best suited to the connected television.
• To enjoy high definition video up-converted to 1080p, you
need to connect the unit directly to 1080p compatible
HDTV (High Definition Television). If this unit is connected
to an HDTV through other equipment, it must also be
1080p compatible.
24p Output
When this unit is connected to a TV supporting 1080/24p
output using an HDMi cable, movies and other material
recorded at 24p are output at 24p.
• When playing DVD-Video, set to “On" and then also set
“24p" in “Video" (o 35) to “On".
• When BD-Video images other than 24p are played,
images are output at 60p.
HDMI Color Mode
This setting is for selecting coior-space conversion of the
image signal when the unit is connected using an HDMI
cable.
HDMI Audio Output
This setting selects whether or not to output audio from
HDMi. Audio wiii be output through the system's speakers
when "Off" is selected.
VIERA Link
Set to use “HDAVI Control" function when connected with
an HDMi cable to a device that supports “HDAVi Controi".
• Select “Off" when you do not want to use “HDAVI Control".
Deep Color Output
This setting is for seiecting whether to use Deep Coior
output when a television that supports Deep Color is
connected.
Contents Type Flag
Depending on the piayback content, the TV wiii output
adjusting to the optimal method when a TV that supports
this function is connected.
Power Off Link
Select the desired power off iink setting of this unit for
ViERA Link operation (o 32). (This works depending on the
settings of the connected VIERA Link “HDAVI Control"
compatible equipment.)
Video/Audio:
When the TV is turned off, this unit wi
Video:
When the TV is turned off, this unit wil
the foiiowing conditions:
- CD or MP3 audio piayback
-iPod/i Phone mode
- Radio mode
-“AUX",“ARC" or “D-iN 1" (DiGITAL iN 1) mode
(non-selected TV AUDiO setting for ViERA Link)
-“D-iN 2" (DIGITAL IN 2) mode (non-selected CABLE/
SAT AUDIO setting for VIERA Link)
turn off automatically,
turn off except during
:leo is dispiayed as a 4:3 ratio image in the
center of the screen.
