Electrical Connections

Caution:

• This product is designed to operate with a 12 V

DC, negative ground battery system.

• To prevent damage to the unit, be sure to foiiow

the connection diagram below.

• Remove approximately W' (5 mm) of protective

covering from the ends of the leads before con

necting.

• Do not insert the power connector into the unit

until the wiring is completed.

* Be sure to insulate any exposed wires from a

possible short-circuit from the car chassis.

Bundle all cables and keep cable terminals free

from touching any metal parts.

• Remember, if your car has a drive computer or a

navigation computer, the data of its memory

may be erased when the battery terminals are

disconnected.

□ Wiring Diagram

Antenna

—

External amplifier control power lead

(max. 500 mA)

(BlueMile stripe)

This lead is for connection to the power amplifier.

Note:

• This lead is used for power control when an external power amplifier

is connected. The power supply of a power amplifier will be activated

when turning on the power of this unit.

Antenna control lead

(to motor antenna) (max. 500 mA)

This lead is not intended for use with switch actuated power

antenna.

(Blue)

Note:

• The power antenna extends automailcally

when the AM/FM radio mode is selected.

ACC power lead

To ACC power, -h12VDC.

ACC

(Red)

Battery lead

To the car battery, continuous -i-12 V DC.

BATTERY 15 A

(Yellow)

Ground lead

To a clean, bare metallic part of the car chassis.

(Black)

CQ-DP383U
