First complete the electrical connections, and then
check them for correctness, (page 48)
Q
Installation Procedures
© Power
connector
The included mounting collar 0 is designed
specifically for this unit. Do not use it to attach
any other model.
Insert
mounting
collar
0
into
the
dashboard, and bend the mounting tabs
out with a screwdriver.
Mounting
springs (^)
Mounting holes
© Mounting bolt
Mounting springs {^)
Engage the mounting
springs (^) in the
mounting
holes
of
the mounting collar
0 firmly.
Mounting springs
g— Mounting
hole
(a) Using the rear support strap (|)
Fire wall of car
© Tapping screw
3 mm0
© Hex. nut
Rear support
strap_________
© Mounting bolt
0 Mounting collar
The tabs to be bent vary depending on the
car. To securely install the unit, fully bend
a number of the tabs so that there is no
rattling.
Example:
0 Mounting colloar
4)
Secure the rear of the unit.
After fixing mounting bolt © and power con
nector ©, fix the rear of the unit to the car
body by either method
(a) or (b) shown below.
Insert trim plate©.
After installation,
" reconnect the nega
tive ©battery ter
minal.
(b) Using the rubber cushion (option)
Rear support bracket
Rubber cushion (option) (provided on the car)
® Mounting bolt
4^ 0 Mounting collar
CQ-DP383U
45
