On-Screen Displays (OSD)
Channel & Function Display
Whenever the channel is
changed, the channel
number will appear for a
few seconds on-screen.
{Some station names may
also appear.)
When a function button is
pushed {PLAY, FF, etc.), the
Combination VCR mode will
be displayed.
• When a recording is started, both REC and
the channel number will appear together.
Menu Screen
Warning and Instruction Displays
These displays will alert you of a missed operation or provide
further instructions.
If no active channels are found
for CHANNEL MEMORY...
{see page 6.)
If you attempt to set or review a
Timer Recording or set the On
Timer and the Clock is not set...
(see pages 10, 11.)
NO CH FOUND
PLEASE CHECK ANTENNA
CABLE CONNECTION THEN
PUSH CH UP KEY AGAIN
PLEASE SET CLOCK
BEFORE PROGRAMMING
Push MENU to display
the MAIN MENU.
Push A t OE> and
MENU to make your
selection {see page 10).
• To get the most from
each feature, please
read the Operation Manual before
attempting any operation.
MAIN MENU
If you push REC on the remote
control or the Combination
CHECK CASSETTE
~TV~ JiRGOSGE
VCR, and a cassette is inserted
RECORD TAB
[$] CE cm with no record tab...
CH CLOCK EXIT
SELECT KEY
SET :MENU KEY
(see page 5.)
VCR Status & Clock Display
Push DISPLAY to display and remove
the overlay shown below.
Current Time
Function Status / channel & Call Letter
Rec Time
Remaining
(OTR mode only
see page 19.)
REC 12:00AM Wh
0: 25 0:00:00
SL£
Tape
Counter
Tape Speed
Dew Detection System
To prevent damage to your tapes, this unit is
equipped with a dew detection system. When
moisture condensation is detected inside the
Combination VCR, “DEW” will appear on-screen
for a few seconds. If a tape is inserted, it will be
ejected. Also, VCR functions will be non-
operational until dew condition passes. Push
DISPLAY to see if dew condition still exists. In
order to avoid this condition, try not to move the
unit directly from a cold place to a warm place.
TV functions are not affected.
Blank Tape/ No Video Signal Indication
When a blank section of tape comes up in Play
mode, or the selected channel has no broadcast
signal, the TV screen will turn solid blue.
If you push PLAY, FF, REW, or
REC on the remote control or
the Combination VCR without
a cassette inserted...
{see pages 18, 19, 22.)
If Combination VCR is not in
Stop mode or a cassette with
record tab is not inserted two
minutes before a Timer
Recording is about to begin...
(see pages 20, 21.)
If head cleaning becomes
necessary while playing
back a tape...
(see page 5.)
If you push a function button
other than STOP/EJECT or
POWER while the Combination
VCR is in VCR Lock mode...
(See page 23.)
If moisture condensation
is detected inside the
Combination VCR...
NO CASSETTE
PLEASE INSERT A CASSETTE
PLEASE PREPARE
FOR TIMER REC
VIDEO HEADS MAY
NEED CLEANING
PLEASE INSERT HEAD
CLEANING CASSETTE
OR REFER TO MANUAL
END:PLAY KEY
VCR LOCK ACTIVATED
12
