TPS300 Mining Manual-1.0.0en
Peg Survey
8
Start and execution Peg Survey
Input Station
PtID : 100
hi : -1.265 m
Start "Peg Survey" from
the program menu.
Start-up menu:
> Step 3 Choose "Start" and
press , then
enter point number
(PtID) and
instrument height
(hi) for the station.
The sign for the
instrument height
(hi) is normally
negative.
PROGRAMS
PEG SURVEY
FLP
SETTING OUT
Choose "Peg Survey" and press
.
> Step 1 Select a job.
> Step 2 Confirm the set of
tolerances.
Sample dialog: > Step 4
Set Point number
(PtID) and
instrument height
(hi).
Leaves "Input
Station" and returns
to the start-up menu.
