background image

TPS300 Mining Manual-1.0.0en

Peg Survey

10

Sequence:

It defines the measuring
sequence.

Options:

• BFFB

Backsight-Foresight-
Foresight-Backsight

• BFBF

Backsight-Foresight-
Backsight-Foresight

• BBFF

Backsight-Backsight-
Foresight-Foresight

Leaves this dialog
and proceed to the
next dialog.

Set 1

of total 3

Proceeding Peg Survey

Sample dialog:

Set 1 of total 3
Start with measurement first set
of three.

Leaves this dialog
and proceed to the
next dialog.

Measure Backsight Point
Information about which
backsight point the user has to
measure.

Leaves this dialog
and proceed to the
measure dialog.

Measure Backsight Point

PtID:

150

Sample dialog:
