TPS300 Mining Manual-1.0.0en
Grades
22
Results, continued Saving data
The following result data are
stored in the internal memory:
Measurement data:
PtID: Point number
Hz: Horizontal angle
V: Vertical angle
HD: Horizontal distance
SD: Slope distance
dH: Height difference
Coordinates of new gradeline
point:
E: Easting
N: Northing
H: Height
Grades Result:
daH: Stake out height
difference
daHD: Horizontal distance
along the foresight
line
Grd: Slope gradient
GE: Grade elevation
If the sign is
negative the grade
point are above the
measure point.
If the sign is positive
the grade point are
below the measure
point.
> Step 6 Turn the telescope
until the height
difference (dHgt) is
zero, then repeat the
measurement
(
> Step 5 ).
