Grades
19
Mining_z06
Start and execution Peg Survey, continued
Mining_z05
150
1
H
New Gradeline
> Step 1 Enter the slope
gradient
(proportion e.g.
1:150).
Slope gradient explained:
Gradeline
> Step 2 Enter the height
difference.
Height difference explained:
H: Current height of
gradeline above
mine floor
dH: Height difference
dH
> Step 3 Set the
entered values and
proceeds to the
gradeline marking
dialog.
Leaves the
application "Grades"
and return to the
menu dialog of
"FLP".
Station Foresight Point
