TPS300 Mining Manual-1.0.0en

Offset

24

Before starting Offset

• Station setup

• Application "FLP" is done

Start and execution Offset

Menu dialog of "FLP":

OFFSET

PtID :

100

Offset:

1.500 m

LEFT

Hz

:

123°12'36"

HD

:

-----.--- m

Sample dialog:

> Step 1

Enter a desired point
number (PtID) and
the offset value.

> Step 2

Using

for the offset
definition.

(Left, Up, Right, Down)

(Left, Down, Right, Up)

Start "Offset" after "FLP" (Front
Line Peg) choose

and press

.

CONTINUE WITH

GRADES

OFFSET
