TPS300 Mining Manual-1.0.0en
Peg Survey
12
Foresight Point 1/3
PtID : 151
Hz : 198°12'45"
V : 94°45'23"
hr : -1.632 m
HD : ----.--- m
Proceeding Peg Survey, continued
Reject the
measurement and
measure the set
again.
Accept the result
and continue with
the next set.
Sample dialog:
> Step 8 Enter the reflector
height (hr) for the
foresight point, if
required.
The sign for the
reflector height (hr)
is normally negative.
> Step 9 Aim at foresight
point and measure.
, ALL, or DIST/REC
Angle and distance
measurements are
triggered and stored
in the internal
memory.
Terminates the
program and returns
to the start-up menu.
Repeat > Step 6
and > Step 9 until
all sets are
measured.
If the tolerances
after a set are not
met, the user has
the option to
continue with the
measuring or
rejecting the data.
