TPS300 Mining Manual-1.0.0en
Mining Editor
30
First Example (Creating fixpoint files, define tolerances, uploading), continued
> Step 5
a) Select a tolerance type
(Primary, Secondary,
Tertiary).
b) Enter the values for:
• Horizontal Angle Limit
• Horizontal Distance Limit
• Height Limit
Upload Fixpoints and
Tolerances to the instrument
Ensure that the unit
setting on the
instrument (Menu /
All Settings / Unit
Settings) is identical
to the units set in
the "Mining Editor"
(
Options
à
Settings).
> Step 1 Open a fixpoint file:
File
à
Open
> Step 2 Choose Upload:
Data
à
Upload
> Step 3 Select a job.
> Step 4 Enter jobname,
operator and
comments.
Operator and
comments are
optional.
> Step 5 Select a tolerance
type.
