85
Figure 5-8
5.3.5 Network
Here is for you to input network information.
z
IP address: Here you can input IP address.
z Network Mode : Includes multiple access, fault tolerance, and load balancing
z Default Network Card: Please select eth0/eth1/bond0(optional) after enable multiple
access function
z Main Network Card: Please select eth0/eth1(optional).after enable multiple access
function.
Note: 960H series support the above three configurations and supports functions as
multiple access, fault-tolerance and load balancing.
z DHCP: It is to auto search IP. When enable DHCP function, you can not modify IP/Subnet
mask /Gateway. These values are from DHCP function. If you have not enabled DHCP
function, IP/Subnet mask/Gateway display as zero. You need to disable DHCP function to
view current IP information. Besides, when PPPoE is operating, you can not modify
IP/Subnet mask /Gateway.
z TCP port: Default value is 37777.
z UDP port: Default value is 37778.
z HTTP port: Default value is 80.
z RTSP port: Default value is 554.
z Max connection: system support maximal 20 users. 0 means there is no connection limit.
z Preferred DNS server: DNS server IP address.
z Alternate DNS server: DNS server alternate address.
z Transfer mode: Here you can select the priority between fluency/video qualities.
z LAN download: System can process the downloaded data first if you enable this function.
The download speed is 1.5X or 2.0X of the normal speed.
After completing all the setups please click save button, system goes back to the previous menu.
