16
Working
Humidity 10%－90%
Air Pressure 86kpa－106kpa
Dimension 2U standard industrial case. 440(W) x460 (D) x89mm(H)
Weight 6.5-7.5KG(Exclude HDD)
Installation
Mode Desktop/rack installation
1.3.5 2U Series （HD-SDI series）
Parameter
4-ch
Main
Processor
High-performance industrial embedded micro controller
OS Embedded LINUX
System
Resources Multiplex operations: Multiple-channel record, multiple-channel playback
and network operation simultaneously
Interface User-friendly graphical user interface
Input
Devices Front panel, USB mouse, remote control
Input
Method Arabic number, English character, donation and extension Chinese
(optional)
System
Shortcut
Function Copy/paste operation, USB mouse right-key shortcut menu, double click
USB mouse to switch screen.
Video
Compressio
n
H.264
Compression
Standard
Audio
Compressio
n
G.711A
Video Input 4-CH composite video input: (NTSC/PAL) BNC (1.0V
B
P- P,
B
75Ω)
Video
Output
1-ch PAL/NTSC, BNC (1.0VP- P, 75Ω) composite video signal output.
1-ch VGA output.
1-ch HDMI output.
Support TV/VGA/HDMI video output at the same time.
Video
Standard
PAL (50f/s), NTSC (60f/s)
Record
Speed
Real-time Mode: PAL 1f/s to 25f/s per channel and NTSC 1f/s to 30f/s
per channel
Video
Partition 1/4 windows
Monitor
Touring Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
Resolution
(PAL/NTSC
)
PAL(50f/s)，NTSC(60f/s)
Real time 1080P(1920*1080)
Recording playback channel1/4: 1080P 1920*1080 720P 1280*720
D1 704Ч576/704Ч480 ; CIF 352Ч288/ 352Ч240;
QCIF 176Ч144/176Ч120
Dual-stream supported: Extra stream resolution1080P 1920*1080 720P
1280*720
D1 704Ч576/704Ч480 ;CIF 352Ч288/ 352Ч240 ;
QCIF 176Ч144/176Ч120
Video monitor
Quality 6-level image quality (Adjustable)
