DVR systems DVRxx04HF-S Series - Manual (Page 20)

10
Monitor
Touring Support monitor tour functions such as alarm, motion detection, and
schedule auto control.
PAL/NTSC
Real-time monitor：
D1 704Ч576/704Ч480
Playback channel 1/16：
D1 704Ч576/704Ч480 ;
HD1 704Ч288/704Ч240;
BCIF 352Ч576/352Ч480;
CIF 352Ч288/ 352Ч240;
QCIF 176Ч144/176Ч120
Resolution
(PAL/NTSC
)
Support dual streams.
Extra stream resolution:
CIF 352Ч288/ 352Ч240
QCIF 176Ч144/176Ч120
Quality 6-level image quality (Adjustable)
Privacy
mask Support one privacy mask of user-defined size in full screen.
Support max 4 zones.
Information
Channel information, time information and privacy mask zone.
TV Adjust Adjust TV output zone suitable to anamorphic video.
Channel
Lock Cover secret channel with black screen though system is encoding
normally.
Screen-lock function to prevent unauthorized user seeing secret video.
Channel
Information Channel name, recording status, screen lock status, video loss status
and motion detection status are shown on the bottom left of display
screen.
Color
Configuratio
n Hue, brightness, contrast, saturation and gain setup for each channel.
Audio Input
4-ch 200-2000mv
10KΩ(BNC) 8-ch 200-2000mv
10KΩ(BNC) 4-ch 200-2000mv
10KΩ (RCA)
Audio
Output
1-ch audio output 200-3000mv 5KΩ(BNC) 1-ch audio output
200-3000mv
5KΩ(RCA)
Audio
Bidirectional
Audio
1-ch audio talk output 200-3000mv 5KΩ(BNC) 1-ch audio output
200-3000mv
5KΩ(RCA)
Hard Disk 2 built-in SATA port. Support 2 HDDs.
Hard disk
Hard Disk
Occupation Audio：PCM 28.8MByte/h
Video：56-900MByte/h
Recording
Mode
Manual recording, motion detection recording, schedule recording and
alarm recording
Priority: Manual recording> alarm recording>motion detection
recording>schedule recording.
Recording
Length 1 to 120 minutes single record duration (Default setup is 60 minutes)
Playback
Repeat
Way
When hard disk is full, system can overwrite previous video file.
Record
Search Various search engines such as time, type and channel.
Record and
playback
Playback
Mode Various fast play, slow play speeds, manual frame by frame playback
and reverse play mode.
