N525 Ethernet Termination Service Unit 3-3
Management User Interface
The Management User Interface for the N525 provides screens for setup, monitoring,
and diagnostics. You can access the screens directly by connecting to the serial port of
the N525 or using Telnet.
General Screen Format
A typical screen, shown in Figure 20, includes standard descriptions and reference
designations. Use this and other screens to configure the system, set operational
parameters, and verify the system status. All screens use a common method for
navigation.
Figure 20 - General Screen Format
Not all screens and menus provide options that you can change. Some menu items
reach screens that only report status, such as revision numbers, module type, or alarms.
On other screens, you can move through and select options, and enter data.
Use these keys to navigate the screens:
• Space bar: When a menu item is highlighted, press to cycle through all
options for that item.
• Tab: Press to move the highlight to the next column to the right.
• Enter: Press to select the highlighted option for a menu item.
• Escape Press once to cancel changes for the selected item or to return to
the previous screen; press two or more times to return to the Main Menu
from two or more menu levels deep.
Canoga Perkins Corp. Ethernet Termination Service Unit 29-Nov-2006
Model N525-5 V96.05 F96 N525 DC_172.16.142.225 07:35:10
---------------------------------------MAIN MENU--------------------------------
1) System Configuration
2) Diagnostics
3) Port Information
4) System Alarms
5) System Log
6) Utilities
7) Software Upgrade
8) Manage Logged In Users
9) 802.3AH OAM
10) Logout
Select [1-10]:
------------------------------------Messages------------------------------------
Model
Navigation
Instructions
Messages and
Urgent Status
Menu
