• Privacy Password: If the privacy protocol is DES, enter the password that generates the
encryption key for the message; 8 to 15 characters
• Privacy Key: Shows the key that encrypts the message for DES Privacy Protocol; this is
generated automatically for the Privacy Password, but can be changed if the destination uses
a different Privacy Key generation algorithm; 16 Hex characters
• Security Level: Can be "No Auth/No Priv," no user authentication or encryption for the
message; "Auth/No Priv," authenticates by user name, but no encryption for the message; or
"Auth/Priv," authenticates by user name and encrypts the message.
• Retries: How many times to try to resend the message if not acknowledged; Range is 0 to 10
• Timeout in Seconds: How long to wait, in seconds, for an acknowledgement before retrying;
Range is 1 to 30
6. To delete a destination, type 3 and press , then at the prompt, highlight the IP Address for
that Host and press . The host table appears again with your changes.
7. To return to the System Menu, press .
Managing the Interfaces
Managing the interfaces consists of setting up and monitoring the parameters for each port, as well as
setting up and monitoring switch parameters. The Port Information screen offers options to set up
and check individual interface ports; see Table 5. Switch Configuration menu offers options to set
network parameters; see Table 6.
Table 5. Port Information Screen Options
Menu Item Description
1. View Module Select a single (S) or multiple (M) port module
2. Port Config/Status Set and view parameters for an individual port
3. Port Statistics View current statistics for data flow through a port
4. Clear Counters on All Ports Reset all statistics to zero and restart counting
Table 6. Switch Configuration Menu Options
Menu Item Description
1. Global Spanning Tree Parameters Set the network-wide parameters
2. Multiple Spanning Tree Parameters Set and view Multiple Spanning Tree instances
3. Global Spanning Tree Report View current network-wide parameters
4. Lag Configuration View the current information for the network and port
5. VLAN Configuration Set the VLAN parameters
6. Double Tagging Configuration Set up double tagging in a service provider environment
9151 Network Interface Device 3-15
