Login and the 9151 Main Menu
The first screen is the Login. If this is your initial setup and no user name or password has been set,
type admin and press at the prompts for the username and password. Otherwise, type your
username and press , then type your password and press .
The Main Menu appears after you log in and provides access to all functions for the 9151: setup,
diagnostics, and reports. See Table 3.
Table 3. 9151 Main Menu
Menu Option Functions
1) System Set values for basic system parameters, communication, and security
as well as view basic system information
2) Switch
Configuration Set and view values for network switch parameters
3) Port Information Set and view values for each port
4) Reports View various system information and events
5) Diagnostics Check data quality through latency and jitter tests or PING
6) Utilities Manage software versions and defaults
Managing the 9151
You can manage the hardware and software for the 9151, including communication access.
Configure the 9151 for the System
The System Information screen provides various categories of optional information that system
administrators may track. To access the System Information screen, and follow these steps:
1. From the System menu type 1 , "System Information," and press .
9151 Network Interface Device 3-5
