62
Canoga Perkins
Operating Environment
Temperature 0 to 50 ° C
Humidity 0 to 95% (non-condensing)
MTBF 62,500 hours (calculated)
7.5 2270 Fiber Optic Modem Configurations
2270-S-XXX-XX-XX-X S = STANDALONE
2270-R-XXX-XX-XX-0 R = RACK-MOUNT
* POWER OPTIONS
0- N/A
1- 120 VAC
2- 240 VAC IN-LINE
3- -48 VDC
* CRYSTAL OPTIONS
00- NO CRYSTAL
01- 21.504M
02- 24.704M
03- 16.384M
04- 25.248M
05- 13.824M
06- 921.6K
07- 7.373M
08- 40.00M (DEFAULT CRYSTAL)
09- 12.928M
10- 6.144M
11- 25.856M
12- 230.4K
13- 24.576M
* FIBER OPTIONS
MULTIMODE
01- 850 nm ST, 6 dB loss budget
SINGLE MODE
11- 1310 nm ST, 15 dB loss budget
13- 1310 nm FC/PC, 15 dB loss budget
16- 1310 nm ST, 10 dB loss budget
*INTERFACE OPTIONS
-22
RS-422/RTS LOW/DC37
-32 RS-232/DB25
-35 V.35/MRC34
-D22 HIGH-SPEED (20Mb) RS422/DC37
-D88 MIL 188-114/DC37
-H22 RS-422/RTS HI/DC37
-ECL PROGRAMMABLE BUFFERED ECL; HSSI COMPATIBLE TO 20 Mbps; DB25
** -P53 PROGRAMMABLE 8-BIT BUFFER; (EXTERNAL CLOCK) RS422; DB25
-R30 RS-530/DB25
-TW 422/TWINAX
-TW8 MIL 188-114/TWINAX
-T22 422/5 CONN TWINAX
-T88 MIL 188-114/5 CONN TWINAX
000 NO INTERFACE
** CONSULT FACTORY TO CONFIRM CONFIGURATION
