Page 7 For technical questions, please call 1-800-444-3353. SKU 96035
If you are using one extension cord for 5.
more than one tool, add the nameplate
amperes and use the sum to determine
the required minimum cord size.
(see table a.)
If you are using an extension cord 6.
outdoors, make sure it is marked with the
suffix “W-A” (“W” in Canada) to indicate it
is acceptable for outdoor use.
Make sure the extension cord is properly 7.
wired and in good electrical condition.
Always replace a damaged extension
cord or have it repaired by a qualified
electrician before using it.
Protect the extension cords from sharp 8.
objects, excessive heat, and damp or
wet areas.
recommended minimum wire
gauge For eXtension cords*
(120 Volt)
nameplate
amperes
(at full load)
eXtension cord
lengtH
25’ 50’ 75’
100’ 150’
0 – 2.0 18 18 18 18 16
2.1 – 3.4 18 18 18 16 14
3.5 – 5.0 18 18 16 14 12
5.1 – 7.0 18 16 14 12 12
7.1 – 12.0 18 14 12 10
-
12.1 – 16.0 14 12 10
- -
16.1 – 20.0 12 10
- - -
table a
* based on limiting the line
voltage drop to five volts at
150% of the rated amperes.
symbology
Double Insulated
Canadian Standards Association
Underwriters Laboratories, Inc.
V~
Volts Alternating Current
a
Amperes
n0 xxxx/min.
No Load Revolutions per Minute
(RPM)
