Page 18 For technical questions, please call 1-800-444-3353. SKU 96035
please read tHe Following careFullY
THE MANUFACTURER ANd/OR dISTRIBUTOR HAS PROvIdEd THE PARTS LIST ANd ASSEMBLy dIAGRAM IN THIS MANUAL AS A
REFERENCE TOOL ONLy. NEITHER THE MANUFACTURER OR dISTRIBUTOR MAkES ANy REPRESENTATION OR WARRANTy OF ANy
kINd TO THE BUyER THAT HE OR SHE IS qUALIFIEd TO MAkE ANy REPAIRS TO THE PROdUCT, OR THAT HE OR SHE IS qUALIFIEd
TO REPLACE ANy PARTS OF THE PROdUCT. IN FACT, THE MANUFACTURER ANd/OR dISTRIBUTOR ExPRESSLy STATES THAT ALL
REPAIRS ANd PARTS REPLACEMENTS SHOULd BE UNdERTAkEN By CERTIFIEd ANd LICENSEd TECHNICIANS, ANd NOT By THE
BUyER. THE BUyER ASSUMES ALL RISk ANd LIABILITy ARISING OUT OF HIS OR HER REPAIRS TO THE ORIGINAL PROdUCT OR
REPLACEMENT PARTS THERETO, OR ARISING OUT OF HIS OR HER INSTALLATION OF REPLACEMENT PARTS THERETO.
parts list
#51 1 - Two Carbon Brushes are installed; two replacement Brushes are included.
Parts with one or two asterisks are not available individually. You must purchase the parts kits.
#94* - Bearing kit includes part numbers 11*, 18*, 59*, 68*
#95** - Seal kit includes part numbers 5**, 8**, 22**, 32**, 35**, 37**, 40**, 63**, 69**, 70**
part description Qty
1 Screw 4
2 Cover 1
3 Crankshaft Box 1
4 Connecting Rod 1
5** Fixing Ring 1
6 Piston 1
7 Spring Hammer 1
8**
O-ring
1
9 Cylinder Box 1
10 Screw 4
11* Bearing 1
12 Pin 1
13 Felt Washer 1
14 Bearing 1
15 Axle 2
16 Bearing Assembly 1
17 Gear 1
18* Bearing 1
19 Adjust Washer 1
20 Snap Ring 2
21 Gear 1
22** Seal Spacer 1
23 Gear Box 1
24 Shock Absorber 2
25 Screw 9
26 Spline Assembly 2
27 Spline Axle 1
28 Nut 2
29
Left Balancing
1
30 Fixing Sheath Washer 1
31 Fixing Sheath 1
32** Spring 1
part description Qty
33 Fixing Sheath 1
34 Hammer Cylinder 1
35**
O-ring
2
36 Clamp Base 1
37** Spring 3
38 Washer 3
39 Nut 3
40** Rubber Washer 2
41 Pin 1
42 Clamp Frame 1
43 Roll Pin 2
44 Shell 1
45 Wire Protector 1
46 Stator 1
47 Stator Compressor 2
48 Screw 2
49 Rotor 1
50 Wire Board 2
51 1 Carbon Brush 4
52 Screw 2
53 Carbon Brush Holder 2
54 Screw 2
55
Wind Lead Ring
1
56 Vane 1
57 Tail Cover 1
58 Screw 9
59* Bearing 1
60 Nut 1
61 Rear Cover 1
62 Washer 2
63** Rubber Seal 1
64 Bearing 1
part description Qty
65 Fixing Sheath 1
66 Sheath 1
67 Crankshaft 2
68* Bearing 1
69** Seal Washer 1
70** Seal Cover 1
71
Right-down Cover
4
72 Screw 4
73 Screw 1
74 Right Balancing 2
75 Nut 1
76 Switch Box 1
77 Switch 1
78 Switch Sheath 2
79 Screw 1
80 Switch Box Cover 1
81 Capacitor 1
82 Terminal 1
83 Cable Clip 2
84 Screw 1
85 Cable 1
86 Trigger 1
87 Switch Knob 1
88 Roll Pin 1
89 Right Handle 4
90 Screw 2
91 Nut 1
92
Left Handle
1
93 Screw 4
94* Bearing Kit
95** Seal Kit
96 Bushing 1
