SECTION V: APPENdIX B. CHANgE 7.0 INFORMA-
TION
HOW TO FLY TYPICAL TCAS II COMMANdS
the resolution advisory is incorporated into the Vertical Speed
Indicator. By illuminating green and red light bands around the dial,
“Fly-to” and “Fly-away-From” commands are displayed coinciding
with the required vertical rate. Maneuver the aircraft promptly and
smoothly in response to the resolution advisory.
Some of the typical resolution advisories shown on the ra/VSI will
require a maneuver by the crew while others will warn against
maneuvering. a typical tCaS II maneuver requires crew response
within 5 seconds and G-forces of ±.25G.
the following diagrams illustrate typical tCaS II encounters showing
intruder traffic on a display and the corresponding resolution on the
ra/VSI.
