BPP-700 Lock up for Primo belt

drives 1990-2007.

Pressure plate with 42-5/16 “
chromium steel ball bearings.

Place BDL diaphragm over ball

bearings then use Primo retainer,

adjustment screw and bolts and

install assembly onto Primo

clutch basket using procedure

outlined above. Re-adjust clutch
per Primo instructions.

BPP-500 Lock up for HD 1998-2007

BDL pressure plate with 45- 5/16”

chromium steel ball bearings.

Install with stock HD diaphragm,

retainer and bolts and install as per

HD manual. Re-adjust clutch as per
HD manual.
