7. Perform final lock down of jam nuts. slide any rubber boots back into place, Replace any
removed Gaskets, Fluids and Covers.
8. Test ride motorcycle and verify proper clutch operation. Easy to shift, Easy to find neutral, No
dragging at light with clutch lever pulled in, No slipping of clutch under riding conditions easy
or hard.
PROCEDURE 2
1. Loosen in line cable adjuster jam nut and fully collapse the in line cable adjuster.
2. Loosen the clutch cable adjuster screw jam nut and back out adjuster screw "counter
clockwise" 1 complete turn.
3. Slowly turn adjuster screw inward "clockwise" until you feel the adjusting screw meet
resistance.
4. Back out adjusting screw 1/4 to 1/2 turn.
5. Snug up the adjuster jam nut, adjust cable free play to the desired 1/8" from inside edge of
cable Ferrule to outside edge of clutch perch, snug up cable adjuster jam nut and test clutch lever
pull and clutch pressure plate travel, You should be able to pull in clutch lever and be able to turn
pressure plate. Minimum travel of pressure plate should be no less than .060" to disengage clutch
plates.
6. Perform final lock down of jam nuts. Slide any rubber boots back into place. Replace any
removed gaskets, fluids and covers.
7. Test ride motorcycle and verify proper clutch operation. Easy to shift, Easy to find neutral, no
dragging at light with clutch lever pulled in, no slipping of clutch under riding conditions easy or
hard.
