OFNA Racing LD3 Pro - Manual (Page 2)

Diff Oil -
Silicone
REQUIRED FOR OPERATION
THINGS NEEDED
AA Batteries ( 12 pcs )
Glow Fuel
20%
TOOLS NOT INCLUDED IN KIT,
BUT NEEDED TO MAINTAIN YOUR CAR.
Phillips Type Screw Drivers ( L )
Phillips Type Screw Drivers ( S )
Needle Nose Pliers
Cutter
Curved Scissors
Knife
Instant Cement
Cross Wrench
#17109 $3.95
Glow Plug & 17MM Cross Wrench
#10801 $6.95
You need to get batteries for the radio transmitter and the car receiver packs.
• Radio TX needs (8) eight AA batteries.
• Car needs (4) four AA Ni-cad batteries, Alkaline type batteries will work, but
braking will be reduced. The best is to use a 5 cell hump pack for increased
voltage..
Recommended Option:
You may want to upgrade the car battery pack to a Ni-Cad or NiHm 5 cell
type(600AE). This will give more run time. OFNA # 10211 or 10212 1000NiMh
Hump Pack and NiHm Battery Charger #10214
#10212 NiHm Hump Pack,
see charger 10214.
#10211 NiHm Flat Pack,
see charger 10214.
10214
Over-nite
Charger
You will need to buy a few items to start the engine and run the car.
• Use 20% nitro CAR fuel. Do not use airplane or heli fuels, they will
over heat engine.
• Rear Exhaust .12 engine with SG crankshaft and Slide Carb.
• Buy SHORT glow plugs, OFNA/PICCO Plug (#51007) are long
therefore use two copper washers. Use plugs without idle bar. Always
use two copper washers with Picco glow plugs.
I
MUST READ THIS BEFORE RUNNING
Running a nitro kit is fun and easy, but to make this a safe Precautions
• This kit is not a toy. Always run car with a second
and good experience you must observe a few rules. This
person as a spotter and pitman.
kit is extremely fast, easily over 40MPH, and can seriously
injure someone if you are not careful.
• Hot Parts - The pipe, manifold, engine and head are very
hot and will cause burns.
Where to run car?
• Any running area you choose must be dry. Do not run
• Rotating Parts - Keep hands away from the drive train,
car near any water or wet dirt.
wheels, and engine when engine is running.
• Do not run on public streets. It is very easy to have the
car run over or damaged by hitting the curb.
• Radio - Check batteries life before running the car. If
• Do not operate car in tight confined places. The car is
radio does not have full control of the car with steering
very fast and will easily hit something.
and/or throttle/brake do not run until corrected. Failure to
• Do not run near people or animals.
correct this will result in possible injury and damage to the
• Due noise, you will want to consider the surrounding car or property.
area when operating the car.
• Glow fuel - Do leave the glow fuel unattended with the lid
• Do not operate the car at night. You will not be able to
off. Fuel contains Methanol and Nitro Methane and is
drive it without hitting something.
• Do not operate the car indoors. Engine exhaust is not
flammable and poisonous.
healthy.
Store fuel in cool ventilated location. Refer the glow fuel
Glow Fuel label for additional precautions.
• Glow fuel is poisonous!
• Glow fuel is flammable!
• Car Fuel tank - Never store fuel in car tank, it will ruin the
• Do not leave in fuel bottle with lid off at any time.
engine if left in tank.
• Do not use any fuel other than glow fuel in this engine.
• Always turn off the car BEFORE turning off radio.
First Time Starting the Engine
Caution! When starting engine make sure the following is
• DAMAGE DUE CAR RUN AWAY IS NOT A WARRANTY
observed.
ISSUE.
• Set engine Master needle to 3 turns (rich setting)
• Do not do this alone, get an experienced friend to help at
IF YOU DO NOT BREAK-IN ENGINE
first.
• Fill fuel tank, try not to spill fuel. Do not spill fuel on
CORRECTLY, MAINLY AT LOW RPM,
receiver
YOU WILL BREAK THE CONNECTING
• Hold car off the ground, so it will not runaway when first
starts
ROD!
• Turn on Radio and check the linkage before starting
engine.
FAILURE TO NOT READ AND
• Turn on car receiver battery switch.
• Always have an air filter on the carburetor to keep dirt
FOLLOW BREAK-IN ENGINE
out.
Emergency Stopping Engine When Running
INSTRUCTIONS WILL VOID
• Remove air filter and cover carb. intake.
• Squeeze fuel line and hold until engine stops.
WARRANTY!
• With a rag, cover exhaust outlet.
Storing Car After Running
CHECK RADIO SETTING AND
• Remove fuel from tank and fuel lines
• Turn off radio in car
LINKAGE BEFORE STARTING
• Put a few drops of after run in engine to keep it from
rusting.
• Clean oil and dirt from chassis with a degreaser.
The car is very fast
and will too easily hit someone.
