ASSEMBL OF THE FRONT UPPER ARMS
Y
#36860
5x35mm
Turnbuckle
#36690
Front Upper
Arm Ball End
#36690
Front Upper
Arm Ball End
#36860
5X35mm
Turnbuckle
#40537
Front Upper
Arm
#36850
7mm
Ball
#36850
G-25
7mm Ball
¡¯
A
p
p
r
o
x
.
7
.5
m
m
11
¡G
..........X2
..........X2
..........X2
ASSEMBL OF THE FRONT SUSPENSION ARMS
Y
#94008
3x25mm
Hex Screw
#94008
3x25mm
Hex Screw
#40546
3x42.7mm
Arm Shaft
..........X2
..........X2
..........X2
..........X4
#40546
3x42.7mm Arm Shaft
#34041
M3
Nylon Nut
#94041
M3
Nylock Nut
#90020
2.5mm
E-Ring
#90020
2.5mm
E-Ring
#90020
2.5mm
E-Ring
..........X2
..........X2
..........X2
..........X4
..........X2
Makes two rods for left and right
hand-side.
12
ASSEMBL OF THE FRONT STABILIZER
Y
#94035
3x8mm
Set Screw
#94035
3x8mm
Set Screw
#40540
Stabilizer
Ball End
#40540
Stabilizer
Ball End
#40540
Stabilizer
Ball End
#30403
6mm
Ball
#30403
6mm
Ball
#30341
Stabilizer Ball
#30341
Stabilizer Ball
#94006
3x18mm
Hex Screw
#94006
3x18mm
Hex Screw
Assembly for both right and left side.
Assembly for both right and left side.
Assembly for both right and left side.
8mm
