Assembly of the front post – OFNA Racing CD3 RTR User Manual
Page 19
M3x12
Screw
M3x12
Screw
38329
6mm Alum.
Ball & socket
(Gray)(Short
)
38282
6mm Alum.
Ball & socket
(Long)
37360
4mm
Ball & socke
t
37360
4mm
Ball & socket
ASSEMBLY OF THE FRONT SHOCK INTO
SHOCK TOWER
ASSEMBLY OF THE REAR SHOCK INTO
SHOCK TOWER
Snap ball end
into 37360 as
shown.
94004
94004
M3x12mm
Screw
M3x12mm
Screw
Foam Bumper
38294
ASSEMBLY OF THE FRONT POST
M3x12mm
Screw
M3x16mm
Flat Head
Screw
M3x16mm
Flat Head
Screw
M3x8mm
Screw
M3x8mm
Screw
94002
94021
94002
94004
94021
94020
94020
Snap ball end
into 37360 as
shown.
