Assembly of the rear stabilzer – OFNA Racing CD3 RTR User Manual

Page 12

38518

2.5mm
E-Ring

M3X3mm
Set Screw

M3X16mm
Screw

M3x3mm
Set screw

M3x16mm
Screw

90020
2.5mm
E-Ring

38420
stabilizer

38418
Stabilizer
Mount

38418
Stabilizer
Balance
Adjuster

ASSEMBLY OF THE REAR STABILZER

Assembly of rear stabilizer

*Keep stabilizer ball in the center.

*Turn stabilizer balance adjuster to
adjust the stabilizer to the same angle.

ASSEMBLY OF THE FRONT STIFFENER
ONTO CHASSIS

ASSEMBLY OF THE REAR STIFFENER
ONTO CHASSIS

38518

Front Stiffener (Left)

Front Stiffener (Right)

M3x8mm
Screw

M3x10mm
Flat Head
HexScrew

38518

Rear Stiffener (Right)

Rear Stiffener (Left)

M3x10mm
Flat Head
Hex Screw

M3x8mm
Screw

Center

94005

94033

94005

94003

94032

94019

94002

94019

94033

94019

94032

94019
