Audio Connections

As a safety precaution, turn all devices (especially power amplifi-

ers) OFF when making connections. Doing so gives you a chance

to find and correct wiring mistakes and prevent damage to your

amplifiers, speakers, ears, pets, etc.

Analog Inputs and Outputs
The RPM 2m has two balanced analog Inputs, two balanced

analog Outputs and one AES3 digital Output.

XLR and euroblock connectors are both provided for your

convenience. Feel free to use either (but not both!) for each

Input. Both Output types may be used if desired. For each Input

or Output Euroblock connector:

• Connect the (positive) audio line to the ‘+’ terminal.

• Connect the (negative) audio line to the ‘–’ terminal.

• Connect the cable shield to the terminal.

For those installations where the RPM 2m internal shield-

to-chassis connection causes interference, connect each shield

directly to the chassis screw located above each Euroblock con-

nector, keeping the shield wrapped around the audio conductors

as much as possible.

For optimum Electromagnetic Interference (EMI) immunity,

connect the shields at both ends of the cable. See the RaneNote

“Sound System Interconnection” for more information on system

connections and proper grounding practices.

Analog Input Stage
Each analog input uses a studio-grade microphone preamp

and an independent line-stage input. The input connectors are

switched between the mic pre and the line stage by a relay that is

controlled by the user interface.

The mic pre has two analog gain stages. The input stage

controls gain in large 15 dB steps. The second analog-gain stage

makes the fine 1 dB gain adjustments. Gain is optimized for best

overload characteristics. If noise performance is of greater impor-

tance, then overload performance can be traded for the best noise

performance by using microphone gains of 15, 30, 45 and 60 dB.

As an example: if the desired mic pre gain is 40 dB, best

overload performance is obtained by setting mic gain to 40 dB

and setting the digital trim to 0 dB. Best noise performance is

obtained by setting mic pre gain to 45 dB and setting the digital

trim to -5 dB (this will cut the top-end headroom by 5 dB). If

this is confusing, just leave the digital trim alone (set to 0 dB)

and use the mic-pre gain slider to set mic gain. For the best noise

performance, only use the digital trim to cut gain.

A high-performance line stage is provided that happily ac-

cepts the hot +24 dBu signals from professional audio sources all

day. When using non-pro -10 dBV audio sources, select the +12

dB line gain level, or for even better noise performance, use the

mic pre at the 15 dB setting and set digital trim to -3 dB. When

you’re hooking up a consumer CD player with a single-ended

output (for example) and you really need an extra 6 dB of gain

(for a total of 18 dB of front-end gain), set the mic pre to 18 dB.

WARNING: when using the mic pre as a low-noise line

stage, make sure the phantom power is turned off!

Analog Output Stage
Analog output is real easy. There is a Digital Trim control located

immediately before the D/A converter. It’s as simple as that.

AES3 Output
AES3 is a popular 2-channel (stereo) digital audio interface

commonly found on professional digital audio equipment

(digital mixers, DAT machines, etc.). Each channel of the AES3

digital stream is treated independently within the RPM 2m.

See the RaneNote “Interfacing AES3 and S/PDIF”, available

from Rane’s website (www.rane.com/library.html), for informa-

tion about interfacing consumer S/PDIF gear to the professional

AES3 standard.

Use the AES3 Output to:

• Feed audio to RPM 88/44/22/26z’s to create a 2-channel digi-

tal “bus” between devices.

• Connect directly to the AES3 input of a digital mixing console.

• Connect directly to the AES3 input of a DAT machine for

recording purposes.

• Connect to an external D/A converter, effectively adding two

more analog outputs.

Control Connections

Versatile Input Port (VIP)
Eight logic input pins are provided, each capable of accepting

DC voltage between 0-5 VDC. VIP pins are used with contact

closure switches for Preset recall, or with potentiometers for

remote Level control. The functionality (Preset recall versus

control) of each pin is assignable as part of the Device Configu-

ration.

• The maximum allowable voltage on any VIP pin is 5.3 VDC.

• Use of twisted pair cable is recommended for lower noise.

• If an external device is used to generate a 0 to 5 volt signal,

connect the ground of the external device to the VIP GND.

Preset Recall Using Contact Closure Switches

The minimum “low” voltage required to detect a contact closure

and change Presets is 2.5 V. Since the internal pull up is 100 kΩ

to +5 V, it is possible to calculate the maximum allowable cable

length, provided the wire resistance per foot (or meter) is known.

Example:

To be safe, let’s allow a maximum of 80 kΩ worth of cable

resistance. This value keeps the voltage divider formed by the

100 kΩ internal resistance and 80 kΩ cable resistance from

dropping below 2.5 V.

(5 V * 100 kΩ) / (100 kΩ + 80 kΩ) = 2.777 V

If the cable resistance is 30 Ω per 1,000 feet (305 meters)

(1,000 ft / 30 Ω) * 80,000 Ω = 2,666,666 ft (813 km)

Thus, you can only use 2,666,666 feet (505 miles) of twisted

pair cable before the Preset recall functionality becomes inter-

mittent (assuming the cable is properly twisted and not run

through excessive magnetic or electric fields).
