79
E
Editing
Recording Over Existing Scenes (AV Insert Editing)
OUTPUT
VIDEO
S(S1)-VIDEO
AUDIO
L
R
S
DV
IN/OUT IN/OUT
IN/OUT
MIC
AV
You can insert new scenes from your VCR or other camcorder onto your pre-
recorded tape using the ZR20’s analog line-in or DV in terminals. Original video
and audio will be replaced with the new video and audio.
REW PLAY FF
SEARCH
SELECT
REC
PAUSE
STOP
PAUSE SLOW ×2
+ / – /
ZERO SET
MEMORY
AUDIO
DUB.
A/V
INSERT
The video and audio of the new scene replace that of the old.
The playback tape
Before inserting
After inserting
The tape in the
camcorder
The tape in the
camcorder
Side with arrow
Side with arrow
S-150 S-video Cable
STV-250N Stereo Video Cable
Insert start point Insert end point
Scene to be inserted
: Signal flow
Make sure the AV/headphone terminal is set to AV through the menu ( 30). If
PHONES appears in the display, switch the terminal.
