WEATHER GUARD Model 8931-3 Parts Box Cabinet - Manual

ASSEMBLY AND INSTALLATION INSTRUCTIONS
Slide Out Rack - Model 8931
Rev. A 4/95 Part No. 24-8931
IMPORTANT
BEFORE YOU BEGIN
Read these instructions and
warnings completely before
installation.
TOOLS REQUIRED
• Screwdriver, phillips
• 7/16" Open or Box End
Wrench (2)
• Electric Drill with 5/16" Drill Bit
Bolt Kit #32-0345 is provided with
your Rack. Check this bolt kit to be
sure the following parts are in
cluded:
Quan. Description
1 1/4-20 Plusnut®
1 Plusnut® Tool
1 1/4-20 x 1-1/4" Blk Ox Bolt
1 1/4" Lock Washer
BOLT KITS
Bolt Kit #709 is provided with your
Rack. Check this bolt kit to be sure
the following parts are included:
Quan. Description
8 1/4" Flat Washer
4 1/4-20 x 1/2" Screw, phillips
4 1/4-20 x 1-1/4" Bolt, hex hd.
4 1/4-20 Nylon Lock Nut
Nylon Lock Nut
Flat Washer
1/4-20x1-1/4" Bolt
Rack Assembly
