— 74 —
(2) If a sufficient area cannot be provided as a result of step
(1), the print area is extended toward the left (So, the left
margin is decreased).
(3) If a sufficient area cannot be provided as a result of step
(2), the right spacing is trimmed.
• When mapping a bit image (Or downloaded bit image), if the
print area is narrower than the minimum width of the bit image
(Two dots for single density, or one dot for double density),
only the line for that image is handled as follows:
(1) The print area is extended toward the left (So, the left
margin is decreased) until it is equal to the minimum width
of the image, but not wider than the printable area.
[Default] nL=64, nH=2 (When 58mm wide paper is used: nL=176, nH=1)
Since the default value varies depending on the number of
columns, refer to “Defing the print area in PAGE MODE; ESC
W”on page 44, for more information.
[See Also] GS L, GS P
(1)
Extended
toward
the right
A
Printable Area
Left Margin (2) The left margin
is trimmed
Print Area Width
