Home Styles 5555-338 - Manual

Key Wrench
(small)
1 pc.
Key Wrench
(large)
1 pc.
Bolt (large)
4 pcs.(+1 extra)
Bolt (small)
4 pcs.(+1 extra)
Flat
Washer (large)
4 pcs.(+1 extra)
Spring
Washer (lage)
4 pcs.(+1 extra)
Spring
Washer (small)
4 pcs.(+1 extra)
Flat
Washer (small)
4 pcs.(+1 extra)
Nut (large)
4 pcs.(+1 extra)
Nut (small)
4 pcs.(+1 extra)
Nut Cap (large)
4 pcs.(+1 extra)
Nut Cap (small)
4 pcs.(+1 extra)
STEP 1
STEP 2
Attach Side Frame (C) and (D) to
Seat (B) with Bolts, Spring Washers,
Flat Washers and Nuts.
Tighten all Bolts with Key Wrench.
Cover all Nuts with Nut Caps.
Attach Back (A) to unit with Bolts,
Spring Washers, Flat Washers and Nuts.
Tighten all Bolts with Key Wrench.
Cover all Nuts with Nut Caps.
Please keep the Key Wrench as you
may need to retighten the Bolts in the future.
A.
Back
1 pc.
B.
Seat
1 pc.
C.
Side Frame
1 pc.
D.
Side Frame
1 pc.
IMPORTANT NOTE
Carefully remove all the parts from the carton and put
them individually on a soft cloth to prevent scratches
or other damages occuring to the wood parts.
We have taken great care in the design of this
product and request that you carefully and strictly
follow our assembly instructions to ensure a
completed product as it was designed.
Part List Hardware List
B
C
D
A
Flat Washer (large)
Spring Washer (large)
Nut (large)
Nut Cap (large)
Bolt (small)
Nut Cap (small)
Nut (small)
Spring Washer (small)
Flat Washer (small)
Bolt (large)
88 5555 80
Arm Chair
Tools required for assembly :
Phillips screwdriver
Home Styles Consumer Assistance Line 888-680-7460 and 877-831-0319
Revised 17Mar2011 [email protected]
IMPORTANT
* Do not tighten up all the screws until each part is properly assembled.
* After assembly, item must be level to work properly. Use the included adjustable levelers to level.
