9200 series top assembly instructions, Step 1 – Home Styles 9100-1012 User Manual
Page 4
Slide the Drawers into place.
Remove Drawers from the unit.
Place the selected ‘Top’ on the unit, attach it to the body with the Steel Plate Connectors,
Flat Washers, Spring Washers and Head Cap Bolts. (See figure 1)
W2
Head Cap Bolt
(short)
Steel Plate Connector
Steel Plate
Connector
Flat Washer
Spring Washer
Head Cap Bolt
(short)
(Figure 1)
STEP 1
9200 Series Top Assembly Instructions
