Assembly Instructions 5/5
STEP 6
(Figure 2)
(Figure 4)
Wood Screw
J
K
K
J
I
I
I
I
Adjustable Pin
Attach the Door Pull Handle to Doors (J) and (K) using Machine Screws. (see Figure 2)
Insert the Adjustable Pins into both Side Panels at the desired level.
Place Shelves (I) into position.
Insert 16X Wood Screws from the back
of the unit and tighten.
(see Figure 4)
Note: Unit must be level
before tightening these screws.
To level the unit, adjust the adjustable
levelers on the bottom of unit.
(see Figure 3)
(Figure 3)
