Assembly Instructions 3/5

B

C

D

E

F

D

F

H

STEP 2

Attach Back Stretcher (D) to
Side Panel (B) using Cam Lock.

Attach Back Stretcher (E) to
Back Stretcher (D).

Slide Back Panels (F) into place.

Attach Back Stretcher (D) to
unit using Cam Lock.

Attach Side Panel (C) to unit using Cam Locks.

STEP 3

Attach unit from Step 2 to Base (H)

using Cam Locks.

Cam Lock

Cam Lock
