Assembly Instructions 2
IMPORTANT
* Please keep Hex Wrench in a safe place as you may need to tighten up the Head Cap Bolts in the future.
* Do not tighten up all the screws until each part is properly assembled.
* Use a soft cloth between these parts and the fl oor.
B
G
B
G
B
E
B F
B
C
/3
Head Cap Bolt
Spring Washer
Flat Washer
STEP 1
Attach Rails (F) and Back Frame (E) to Side Frame (C)
with Head Cap Bolts, Spring Washers and Flat Washers.
(see Figure 1)
Attach Back Frame (D) to unit with Head Cap Bolts,
Spring Washers and Flat Washers.
STEP 2
Attach Shelves (G) to unit
with Head Cap Bolts, Spring Washers and Flat Washers.
Figure 1
B
D
