25
Thermostat Adjustment
Figure 6
The thermostat dial is set to its lowest temperature setting when shipped from the
factory. Remember that lower temperature settings are more energy efficient.
Adjust the temperature by turning the thermostat dial. It is suggested that the starting
point setting not be greater than the ”
“ mark on the thermostat dial (approximately
120°F [48.9°C]) as pictured above. Rotate the thermostat dial clockwise to
decrease the temperature setting. Rotate the thermostat dial counter-clockwise
to increase the temperature setting. Adjust the dial until the minimum
acceptable temperature is achieved (See figure 6 above for approximate temperature
settings).
Figure 7
The thermostat dial is set to its lowest temperature setting when shipped from the
factory. Remember that lower temperature settings are more energy efficient.
Adjust the temperature by turning the thermostat dial. It is suggested that the starting
point setting not be greater than the “
” mark on the thermostat dial (approximately
120°F [48.9°C]) as pictured above. Rotate the thermostat dial counter-clockwise
to decrease the temperature setting. Rotate the thermostat dial clockwise
to increase the temperature setting. Adjust the dial until the minimum
acceptable temperature is achieved (See figure 7 above for approximate temperature
settings).
