Hanging tv's and locking into place – AVF PM-D User Manual
Page 6

P
L
PPP
1
2
3
Hang the TV , First hooking the top of the Mounting Bracket
rail then allowing the TV to rest on the rail.
Note: 2 people should lift and secure the TV as it can be
heavy and awkward.
PP
PM-D
Never leave one TV attached.
Always have someone support the
attached TV as the other side is
hung. This may require 3 people.
Once your TV is centered.
Completely tighten bolt against
metal bracket.
6mm Hex key
Hanging TV's and locking into place
Page 6
of 8
Step 5
VIDEO FURNITURE INTERNATIONAL
190 Don Hillock Drive, Aurora , Ontario L4G OG9 www.video-furn.com
Toll Free: 1-877-834-3876 Fax: 1-905-751-1488 Local:905-751-1459
Make sure Bolt clears bracket, TV will tilt
until its flush with the mount, Tighten bolt
until it catches on the bracket.
