AVF T324 T3 User Manual

Table 324, Page 1, Assembly instructions

background image

Wood Screw 1"

(100)

Philips (+)

Screwdriver

Cordless Drill

and Philips (+)

bit.

7/16 Wrench

or Socket set

Bridge

(1)Short 12"

(1) Standard 36"

Tabletop T

(1)

Table

Leg

(2)

Rack

base

(1)

Rack side

(1)Right Side

(1) Left Side

Rack

door

(1)

Long Bolt

(20)

Cable management

(2)

Rack

Leg

(4)

Grommet

(4)

L-Bracket

(5)

10RU

Rackrail

(2)

Tabletop Surface

(1)

CAM Screw

(30)

3/4" CAM

(30)

Mending plate

(10)

Wood Screw 5/8"

(30)

Table 324

VIDEO FURNITURE INTERNATIONAL

190 Don Hillock Drive, Aurora, Ontario L4G 0G9 www.video-furn.com

Toll Free: 1-877-834-3876 Fax: 1-905-751-1488 Local:905-751-1459

Note: If you cannot understand these instructions or are concerned about the safety of the installation

Contact a qualified contractor or contact VFI at 1-877-834-3876.

For indoor use only

Confirm all parts are included before you begin assembly. Extra hardware is provided and will be left over.

2 people are recommended to assemble this table. Assembly time approx 1 hour.

Thank you for purchasing VFI's 324 Table.

These instructions will guide you through it's assembly.

Additional add-on furniture will have its own instructions.

Supplied Parts:

Supplied Hardware:

Tools required:

(Not Included)

Page 1

of 5

Assembly Instructions

Ver 1.5

Short Bolt

(30)
