Mounting bracket (pm-s only), Step 4-s page 5 – AVF PM-D User Manual
Page 5

B
A
VIDEO FURNITURE INTERNATIONAL
190 Don Hillock Drive, Aurora , Ontario L4G OG9 www.video-furn.com
Toll Free: 1-877-834-3876 Fax: 1-905-751-1488 Local:905-751-1459
M8 X 20 with Locknut
6mm Hex key
A B
=
1.Figure out the location of the bracket.
+ 4" (see below where to measure B distance)
Bolt to the nearest upper hole.
2.Make sure to center the bracket.
3.Tighten all 4 bolts.
13mm Wrench
or Socket
Mounting Bracket (PM-S only)
Step 4-S
Page 5
of 8
