B&C Technologies PF Series - Manual (Page 32)

Table 9.5: Machine Parameters
Number Description Units Standard value Set value
2 Speed of belts mm/min 52000
3 Ski length mm 1700
4 Distance PhC inlet -¿ PhC XF 1 + LE-window mm 2500
5 Distance Photocell XF 1 -¿ XF 1 mm 135
6 Distance XF 1 -¿ XF 2 mm 450
7 Distance XF 1 -¿ Photocell XF 2 mm 570
8 Without Photocell XF 2 0/1 0
10 Distance Photocell stacker -¿ stacker mm 180
11 Position pile A mm 750
12 Position pile B mm 1350
13 Position pile C mm 2000
14 Distance PhC XF 12 -¿ XF 2 mm 0
15 Position sort out mm 3500
16 Distance PhC XF 12 -¿ PhC XF 2 mm 0
17 Width of a stacker length mm 450
18 Bypass-Distance XF 1 -¿ XF 2 mm 0
19 Correction Bypass-Distance PhC XF 2 mm 0
20 Distance XF 2 -¿ start stacker mm 500
21 Distance stop stacker without a piece mm 1500
22 Correction transport out mm 0
25 Distance PhC XF1 -¿ PhC stacker + LE-window mm 2500
30 Stop position in LF mm 1150
32 PhC inlet: time until active ms 16
33 PhC inlet: time until inactive ms 16
41 Shift blow LE XF 2 mm -100
50 Shift fingers XF 1 mm -100
60 Shift reversing XF 1 mm -100
61 Shift reversing XF 2 mm -100
70 Correction reversing XF 1 mm 100
71 Correction reversing XF 2 mm 100
76 Time until under-worked ms 5000
80 Shift knife XF 1 mm 0
81 Shift knife XF 2 mm 0
90 Vertically adjustable input conveyor 0/1 0
96 Enable separate input conveyor 0/1 0
98 Activate PhC Top XF 1 0/1 0
28
