B&C Technologies PF Series User Manual
Page 28
No
Qty
Description
Part.-No
1
6
Cotton belt 88mm L=5500mm
52-0023
2
1
Cotton belt 50mm L=5500mm
52-0001
3
2
Polyester belt 180mm perforated L=5505mm
52-0080
4
2
Cotton belt 50mm L=900mm
52-0001
4
2
Cotton belt 88mm L=900mm
52-0023
5
2
Cotton belt 50mm L=1220mm
52-0001
5
2
Cotton belt 88mm L=1220mm
52-0023
6
2
Cotton belt 50mm L=1840mm
52-0001
6
2
Cotton belt 88mm L=1840mm
52-0023
7
2
Cotton belt 50mm L=1410mm
52-0001
7
2
Cotton belt 88mm L=1410mm
52-0023
8
2
Cotton belt 50mm L=1750mm
52-0001
8
2
Cotton belt 88mm L=1750mm
52-0023
9
2
Cotton belt 50mm L=2440mm
52-0001
9
2
Cotton belt 88mm L=2440mm
52-0023
10
7
Rounthane D1/4 L=1700mm
52-0003
11
2
Rounthane D1/4 L=1350mm
52-0003
12
1
Polyester / Polyester belt 180mm perforated L=3985mm
52-0080
Table 8.2: Lateral fold, Crossfold and Stacker
Figure 8.1: Machine Belt Detail
24
