Page 29: Plc outputs, Output module 01, Chapter 9 plc adjustment, 1 plc inputs, 2 plc outputs

Chapter 9

PLC Adjustment

9.1

PLC Inputs

9.1.1

Input Module 01

Table 9.1: Input Module 1

Number

Description

DI0111

Emergency Stop

DI0121

Overload FC

DI0112

Button start A

DI0122

Button start B

DI0113

Button start C

DI0123
DI0114

Button sort out

DI0124

Photocell XF 1

DI0115

Photocell inlet

DI0125

Photocell XF 2

DI0116

Photocell stacker

DI0126

Button push out

9.2

PLC Outputs

9.2.1

Output Module 01
