E-49
1
RS-232C Interface
For connection to a PC and uploading/downloading of system data
and file data.
2
RS-422 Interface
For connection of multiple Satellite Cradles.
3
AC adaptor jack
For connection of the AC adaptor to supply power.
4
Nose Guide
Remove this guide when you are using the down-facing reader port model.
5
Terminal detection switch
Detects whether or not the Handheld Terminal is mounted correctly
on the Satellite Cradle.
6
System operation indicator
Indicates whether or not system operation is normal.
A system operation problem is indicated when this indicator does
not light up green shortly after the Handheld Terminal is mounted
onto the Satellite Cradle.
Off:
All Handheld Terminals mounted on the Satellite Cradle
are unable to communicate, or there is a system
problem.
Lit Green: Normal system operation. One or more of the Handheld
Terminals mounted on the Satellite Cradles are
communicating.
7
Communication indicator
Indicates the status of communication operations.
Off:
Not communicating
Flashing Green:
Communication in progress
Lit Red:
Satellite Cradle connection problem
8
Spare battery pack charge
Indicates the charge status of the spare battery pack.
Off:
Not charging, or a battery pack problem
Lit Red:
Charging (charging standing by when the battery in the
Handheld Terminal is charging)
Lit Green: Charging complete
9
Battery pack charge indicator
Indicates the charge status of the lithium-ion battery pack in the
Handheld Terminal.
Off:
Not charging (e.g. lithium-ion battery not loaded in
Handheld Terminal) or a battery pack problem
Lit Red:
Charging
Lit Green: Charging complete
10 Power indicator
Indicates whether power is ON or OFF, and if the Handheld
Terminal is mounted.
Off:
Power OFF
Lit Red:
Power ON, Handheld Terminal not mounted
Lit Green: Power ON, Handheld Terminal mounted
11 Desktop guides (L, R)
Holds down the Handheld Terminal on the Satellite Cradle that is
placed on a flat surface in desktop configuration.
12 Charge/Power supply terminals Supplies power to the Handheld Terminal mounted on the Satellite
Cradle.
13 Battery pack charge terminals
Charges the spare battery pack separately.
14 Infrared port
This port provides IR communication capabilities with a Handheld
Terminal.
15 Power switch
Turns power ON and OFF.
16 Base
Reverses the position of the base when wall-mounting the Satellite
Cradle.
17 DIP switches
Use these switches to set the operational configuration of the
Satellite Cradle.
18 Wall mounting holes
Use these holes to attach the Satellite Cradle to a hook on a wall.
indicator (“CHG 2”)
(“CHG 1”)
(“READY/POWER”)
