Casio DT-930 - Manual (Page 47)

E-47
DT-960IOE Basic Cradle Specifications
Infrared
Interface: Infrared
Standard: CASIO original
Control Protocol: Half-duplex
Synchronization: Asynchronous
Speed: 2,400 to 115,200 bps
RS-232C
Control Protocol: Half-duplex
Synchronization: Asynchronous
Speed: 2,400 to 115,200 bps
RS-485
Control Protocol: Half-duplex
Synchronization: Asynchronous
Speed: 2,400 to 115,200 bps
Power Supply
Power Source: AC adaptor (DT-9020ADP-GS or DT-9020ADP-US)
Power Requirements: AC 230 V (DT-9020ADP-GS)
AC 120 V (DT-9020ADP-US)
Rated Input: DC 9.5 V, approx. 1,000 mA
Functions
Infrared interface
RS-232C interface
RS-485 interface
Serial Connection
Up to 16 units
Dimensions and Weight
Desktop: Approx. 110 (W) x 220 (D) x 100 (H) mm
Approx. 400 g
Wall Mounted (with wall mount unit attached):
Approx. 110 (W) x 220 (D) x 110 (H) mm
Approx. 410 g
