Page 7

7
72" Fabricated Deck Spindle Assembly - Parts List for Figure 3
Ref.
No. Part No.
Description
Qty.
1
00005763 Hex Nut, 7/16-14
1
2
00008495 Hex Cap Screw, 3/8-16 x 1-3/4
1
3
00011438 Hex Cap Screw, 3/8-16 x 1-1/2
12
4
00011861 Hex Cap Screw, #/8-16 x 2-1/2
1
5
00011925 Hex Cap Screw, 3/8-16, 4.00
1
6
00012158 Flat Washer, 3/8
12
7
00022560 Flange Lock Hex Nut, 3/8-16
20
8
00060078 Grease Fitting, 1/4-28 x 3/16
2
9
00083192 Idler Washer
1
10
01000302 Shoulder Screw, 7/16-14
1
11
01000364 Hex Carriage Screw, 3/8-16, 1.75
1
12
01000380 Flange Hex Nut, 3/4-16
3
13
01000387 Torsion Idler Spring
1
14
01000389 Lock Washer, 7/16
1
15
01000392 Flat Washer, .781 ID 2.00 OD, .105
1
16
01000393 Flat Washer, .469 ID, .875 OD, .105
1
17
01000643 Carriage Bolt, 3/8-16 x 1
3
18
01000723 Flat Washer, .406 ID, 1.0 OD, .105
6
19
01002751 Spacer, .39 ID x .63 OD x 1.75
1
20
01002771 Cotter Pin, .072 x 1.12 Long
2
21
01003123 Spacer .812 ID x .268 LG
2
22
01003245 Spacer, .39 ID x .625 OD x 2.75
1
23
01004478 Aluminum Spindle Support Plate
3
24
01007499 V-Pulley, 5.75 OD
3
25
01007786 Idler Arm Assembly includes:
1
01000308 Bearing Sleeve
2
26
01007937 V-Belt, B Section x 124.0 Lg
1
27
01008018 Spacer, .760 ID x 2.00 OD x .330
3
28
01008222 Tension Idler U-Bracket
1
29
01008247 Handle Tension Weldment
1
30
01008270 Tension Idler Handle Grip
1
31
01008542 Hex Cap Screw, 3/4-16, 7.50
2
32
01008543 Hex Cap Screw, 3/4-16, 9.50
1
33
01010014 Spacer, .76 ID x 2.0 OD x .790
1
34
02000568 Bahia Blade, 25.0, .756 ID
3
35
02000920 Aluminum Spindle Assembly
3
36
02001574 Spring Tension Rod
1
37
02003489 Idler Arm Assembly includes:
1
01000308 Bearing Sleeve
2
38
02004063 Adaptor Plate
1
39
02004069 Extension Spring, .94 OD x 7.72 Lg
1
40
02004377 V-Belt, B Section x 107.0
1
41
02004379 V-Pulley, 7.450 OD x .750 Bore, Cast
1
42
02004447 Idler Pulley, 4.06 OD
1
43
02005077 Idler Pulley, 4.06 Dia.
1
44
02005079 Idler Pulley, 5.06 Dia.
1
45
00002528 Hex Cap Screw, 3/8-16 x 2.00
1
