5
72" Fabricated Cutter Deck - Parts List for Figure 2
Ref.
No. Part No. Description Qty.
1 00011925 Hex Cap Screw, 3/8-16, 4.00 2
2 00012158 Flat Washer, 3/8 2
3 00012428 Lock Nut, Nylon Insert, 1/2-13 5
4 00014608 Lock Nut, Nylon Insert, #10-32 16
5 00017778 Phillips Head Screw, #10-32 x 1/2 16
6 00022560 Flange Lock Hex Nut, 3/8-16 54
7 01000343 Complete Wheel, 5.00 Dia. 6
8 01000372 Carriage Bolt, 3/8-16 x .75 Lg. 35
9 01000385 Front Roller 4
10 01000398 Wheel Spacer 4
11 01000643 Carriage Bolt, 3/8-16 x 1 6
12 01001169 Grass Catcher Roller 2
13 01001745 Pin, 5/8 Dia. x 1.2 Lg. 4
14 01002010 Carriage Screw, 3/8-16 x 1.25 7
15 01003253 Torsion Spring, 0.4ID x 2.16Lg 1
16 01004304 Hex Index Washer Screw, 3/8-16, .5 8
17 01004684 Belt Cover Support 2
18 01004707 Deck Roller Mount Bracket 3
19 01005438 Outer Belt Cover Support Assembly 2
20 01005869 T-Handle Latch Draw 4
21 01008526 Finger Guard 1
22 01009102 Pin, .375 x 14.06 1
23 01009705 Chute Deflector 1
24 01009842 Discharge Baffle Weldment 1
25 01010119 Nut, 1/2-13, Flangelock 2
26 02000109 Pillow Block, Steel 3
27 02000110 Pillow Block, Steel 1
28 02002800 J-Hook w/ Threaded Roller 1
29 02004410 Right Hand Deck Belt Cover 1
30 02004403 Left Hand Deck Belt Cover 1
31 02002911 Right Hand Deck Lift Bracket 1
32 02002912 Left Hand Deck Lift Bracket 1
33 02004833 Shoulder Bolt, .625 x 3.00 x 3/8-16 2
34 02005696 Baffle, 72" Adjustment 1
35 02004868 Right Hand Front Adjustment Skirt 1
36 02004869 Left Hand Front Adjustment Skirt 1
37 02004872 72" Deck Assembly 1
38 02004874 Chute Deflector Bracket 1
39 02005195 Chute Baffle 1
40 01008049 Carriage Bolt, 3/8-16 x 4.00 2
41 712_0641 Hex Nut, M16-1.5 2
42 721_04041 Water Nozzle Adaptor 1
43 736_0760 Lock Washer, 17 x 23.8 x 1.95 2
44 737_04003C Deck Water Nozzle 2
