Left Hand BDP-12 Hydraulic Pump- Parts List for Figure 29
Ref.
No. Part No.
Description
Qty.
1
HG-70797
Kit, Housing
1
(78)
Housing, Pump
1
2
HG-52038
Kit, Endcap
1
(66)
Plug 9/16-18 (Metal)
1
3
HG-50641
Straight Headless Pin
2
4
HG-50969
Hex Flange Bolt M8-1.25 x 60mm Long
4
5
HG-52629
Housing, O-Ring
1
6
HG-71247
Kit, Charge Pump (STD CHG .19 ci/rev, Thru)
1
(7)
Gerotor
1
(8)
O-Ring
1
(84)
Seal
1
(86)
Housing, Charge Pump
1
10
HG-9007200-3116 Screw, 5/16-18 x 1.00 Long
2
15
HG-71248
Kit, Bypass Valve
1
18
HG-71252
Kit, Pump Shaft (15mm Tapered Keyed Thru)
1
(19)
Bearing, Ball 17 x 40 x 12
1
(79)
Ring, Ret. Wire .561 I.D.
1
(89)
Shaft, Input Tapered Keyed
1
20
HG-51161
Lip Seal 17 x 40 x 7 PTC
1
21
HG-50951
Spacer
1
22
HG-50329
Retaining Ring
1
25
HG-71170
Cylinder Block Kit
1
29
HG-2003014
Block Spring
1
30
HG-2003017
Block Thrust Washer
1
32
HG-2003087
Swashplate
1
34
HG-50551
Ball Thrust Bearing
1
37
HG-50807
Arm, Trunnion Tapered Square
1
38
HG-2000015
Slot Guide
1
42A
HG-70743
Kit, Shock Valve (200 Bar, .031 Orifice)
1
42B
HG-70743
Kit, Shock Valve (200 Bar, .031 Orifice)
1
44
HG-70402
Charge Relief Kit, (1/4 Plastic Ball & 2000029 Spring)
1
49
HG-2513043
Trunnion Seal / Retainer Kit
1
(76)
Ring, Ret. -Star Wash 1.0
1
(77)
Seal, Lip 12 x 25 x 5
1
56
HG-9005110-4400 Plug - 7/16-18 Steel (Diagnostic)
1
90
HG-71172
Kit, Fan
1
(81)
Washer, O.D. Slotted .40 x 1.55 x .06
1
(82)
Fan, 6", 10 Blade
1
(83)
Fan Hub
1
(106)
Nut, Lock, Side 5/16-24UNF-2B
1
100
HG-70525
Overhaul Seal Kit
1
(5)
O-Ring, Housing
1
(8)
O-Ring
1
(20)
Seal, Lip 17 x 40 x 7
1
(22)
Ring, Retaining
1
(76)
Ring, Retaining
1
(77)
Seal, Lip 12 x 25 x 5
1
209
HG-52016
Bracket, Shroud
1
110
HG-70794
Kit, RTN
1
(94)
Arm, Control
1
(98)
Arm, RTN
1
(99)
Assembly, RTN Bi-Directional
1
(102)
Spring, Extension (STD)
1
(103)
Screw, 5/16-24 x .75 (Patch)
1
(104)
Washer
2
(106)
Nut, Lock, Side 5/16-24UNF-2B
1
209
HG-52016
Bracket, Shroud
1
